Metawell VW California

Excellent crash performance

Metawell KTM xbow Unterboden auotmotive

Easy processing

Metawell Rampen Busbau Neuburg

High corrosion protection

Metawell VW California Duchstiegsplatte

Rigid components with low overall height

Vehicle construction with Metawell® lightweight aluminium panels

Energy savings, lightweight construction and recycling are key requirements in vehicle construction. Metawell® aluminium lightweight panels enable these requirements to be implemented in a versatile and consistent manner in passenger cars, sports cars, buses, commercial vehicles and caravans, among others.
Metawell® is successfully used in various designs for small to medium series production as well as for special vehicles in the automotive sector. The wide variety of vehicle types for a wide range of applications places enormous demands on the flexibility of the materials used. Metawell® is particularly suitable for flat applications that require high component rigidity and low weight. Compared to solid aluminium sheets with the same rigidity, a weight reduction of up to 80% can be achieved. With Metawell® Aluflex, moulded components such as diffusers, interior fittings and stiffening elements can be easily realised.
Metawell works closely with renowned automotive OEMs and supplies customised lightweight components: from unprocessed semi-finished sheets to CNC-machined, pre-assembled elements and finished components.

Metawell® & Metawell® Aluflex

Various applications of Metawell® in the automotive sector

Lightweight, stable and functional – perfect for the automotive sector

Typical areas of application include superstructures, high-strength load-bearing body parts, crash elements, interior fittings, ceilings, floors, roofs, side flaps, boot floors, components for manual and electric ramps, and lift systems.
Metawell® at a glance

  • Weight reduction of up to 80% compared to aluminium sheet metal of the same stability
  • Rigidity and crash safety
  • Resistance to corrosion, stone chips and moisture
  • 100% recyclable
  • Compliance with the requirements of the EU End-of-Life Vehicles Directive
  • Primed aluminium sheets with the highest surface quality for optimum corrosion protection
  • Fire approval in accordance with Directive 95/28/EC
Metawell Atacama Caravan

Caravans

Metawell® aluminium panels and prefabricated elements are installed in caravans. They give fittings, cupboards, bed bases and tables the necessary strength without unnecessarily increasing the weight of the vehicle.

  • Low installation height: Increases installation flexibility
  • Bending stiffness & weight: High stiffness with minimal dead weight allows use with few fixing points. Elements can be assembled quickly and efficiently
  • Exceptional crash properties: Due to the possible alignment of the corrugated core and the non-splintering of the material

Components for entry aids

Bus entrance areas have to withstand exceptional stresses – extremely high load cycles, weather-related influences and contact with aggressive substances such as road salt are commonplace here.

  • High load-bearing capacity: Corrosion-protected lightweight aluminium panels withstand extreme surface and point loads
  • Durable and robust: Proven in manual folding ramps and electric ramps as well as in lift systems
  • Weather-resistant: Resists moisture, road salt and other environmental influences
Metawell Rampen Busbau
Metawell Decken Busbau

Panels and components for bus construction

Metawell® lightweight aluminium panels are used in bus construction for ceilings, floors, boot floors, side flaps, robust interior fittings, load-bearing body parts and stiffening elements.

  • Bending stiffness: High surface and point loads, larger spans with low weight
  • Resistance: To corrosion, stone chips and moisture
  • Adaptation to existing design concepts: Individual shaping and colouring through coating, painting, printing, laminating or, on request, powder coating.

Trucks & special Vehicles

Metawell® is frequently used in lorries and special-purpose vehicles (e.g. fire engines, ambulances, etc.), for example for cab rear walls, roofs, floors, shelving systems, fittings and flaps.

  • Appearance: Very smooth surfaces possible
  • Bending stiffness & weight: High stiffness with minimal dead weight allows use with few fixing points. Elements can be assembled quickly and efficiently
  • Corrosion protection: Cover sheets and core material of Metawell® are corrosion-protected, ideal for external weather conditions
Metawell Aufbauten Nutzfahrzeuge Moetefindt
Metawell KTM xbow

Sports cars & passenger cars

Metawell® can be used in a variety of ways in the construction of cars and sports cars: load-bearing body parts, underbody extensions, rear diffusers and crash elements, which must absorb enormous forces through plastic deformation.

  • Crash behaviour: Enormous forces can be absorbed through plastic deformation of the material.
  • Easy shaping: Curved components can also be manufactured.
  • Stone chips: No immediate floor replacement necessary compared to GRP.

Product features

Outstanding product features of Metawell® in the automotive sector
Lightweight. Stable. Excellent crash properties.

Metawell® aluminium lightweight construction panels are suitable for the automotive sector thanks to their combination of low weight and high rigidity with a low material height. Their good crash properties, recyclability and high corrosion protection enable unique solutions to be found.

Engineering expertise – Our dedicated engineering team provides support with design and implementation – even for complex applications.

Exceptional crash properties – The ability to align the shaft core and the non-splintering properties of the material enable excellent crash performance results to be achieved.

Component and system delivery – Thanks to our high level of vertical integration, we can supply components and systems tailored to technical requirements.

Durability due to corrosion resistance – 5000 series aluminium alloys with a minimum magnesium content of 2.7% and the use of an additional primer on all surfaces, including the core material, guarantee exceptionally high corrosion resistance.

Engineering expertise
From sheet to finished component

Metawell® not only offers high-quality lightweight aluminium sheets, but also comprehensive engineering expertise for the automotive sector. Our experience ranges from the initial concept idea to series production – we support our customers in the planning, design and implementation of tailor-made solutions.

Tailor-made solutions: Together with leading OEMs, we develop components that are precisely tailored to vehicle architecture, static requirements and functional needs.

Prototypes and tests: We support the development of prototypes, carry out mechanical tests and thus ensure reliable functionality in series production.

Ready for series production: Our solutions are designed for series production – from the first sample to fully tested series parts. This also includes the creation of technical drawings, production approvals and assembly concepts.

Practical optimisation: Through our close cooperation with vehicle manufacturers, we can optimise processes, reduce weight, shorten assembly times and increase material efficiency.

Easy processing and installation of Metawell®
Easy to work with using standard tools – also suitable for local content projects

Metawell® not only offers outstanding material properties, but also scores highly with its particularly easy and flexible processing. By using standard tools, projects can also be implemented where a high level of local content is to be achieved.

Processing instructions & downloads

We provide the following technical information to ensure safe and efficient processing:

Processing tips
Shaping Metawell® Aluflex

Metawell® products are corrosion-resistant, low-maintenance and durable.
Long-lasting protection and maximum safety

Metawell® products are made from particularly corrosion-resistant aluminium alloys and, thanks to their complete primer protection, are ideal for use in the automotive sector.

Corrosion protection at all levels: Every aluminium layer – even the corrugated core material – is coated on both sides with a specially developed corrosion protection primer. This protective coating clearly distinguishes Metawell® from other products, in which the core material often remains untreated.

Strong hold thanks to perfect adhesive bond: The primer not only protects against corrosion, but also forms the essential basis for a durable and stable adhesive bond – a crucial prerequisite for the longevity of our products.

High-quality alloy for demanding applications: Both the cover sheets and the core material are made of aluminium from the 5000 alloy series with a magnesium content of over 2.7%. These alloys are considered particularly corrosion-resistant and are therefore ideal for use in the automotive sector.

Sustainability
Metawell® lightweight construction solutions for the automotive industry

The use of Metawell® aluminium lightweight panels in the automotive sector is much more than a technical improvement – it is an active contribution to sustainable mobility. The significant reduction in weight significantly lowers energy consumption and emissions over the entire service life of a vehicle.

100% recyclable – no material separation required: Metawell® panels can be completely and easily recycled at the end of their life cycle – without any prior separation of materials.

Made from approx. 80% recycled aluminium: Our products consist of around 80% secondary aluminium – this saves natural resources and reduces the carbon footprint.

Less material. More efficiency: Thanks to the sophisticated design of Metawell®, less aluminium is used.

Raw material bank for your vehicle: Aluminium retains its value. At the end of its service life, Metawell® can be sold as a high-quality secondary raw material.
